Drawer Lock 106

Features

  • It is available in keyed difference (KD), keyed alike (KA) and master key (MK) options.
  • Material is zinc die-cast body & cylinder.
  • The security level is 5 disc tumbler/wafer with 100 key changes.
  • It includes 2 brass keys.
  • Drawer Lock Plate can be purchased separately (Search DS-02 in the search box)
  • Dead Bolt travels 5/16"
  • It is suitable for up to the wood thickness of 7/8" (22mm).
  • Drill hole size 7/8" (22mm)
  • All keyed alike numbers could be used with another style of AMMA locks.

    Part No Description
    AMMA-106-KD AMMA Diamond Back Drawer Lock Nickel Plated #106 Keyed Difference (KD)
    AMMA-106-KA006 AMMA Diamond Back Drawer Lock Nickel Plated #106 Keyed Alike (KA) #006
    AMMA-106-KA001 AMMA Diamond Back Drawer Lock Nickel Plated #106 Keyed Alike (KA) #001
